Direct-Drive HVLS Ceiling Fan
24FT 20FT 18FT 16FT

Energy-saving and efficient ventilation and
cooling equipment suppliers

Bonawind HVLS ceiling fans deliver powerful, energy-efficient airflow for large spaces, ensuring maximum comfort with ultra-low noise.

Driven by an outer rotor permanent magnet brushless DC motor, they offer high torque, low energy consumption, and long service life.

Aerodynamic aluminum alloy blades, reinforced with internal ribs, provide stable, smooth airflow while enhancing strength and preventing deformation.

Each fan generates natural, three-dimensional air movement, promoting better ventilation and a fresher environment across wide areas.

Optional VFD control allows users to easily adjust fan speeds manually, offering flexible and efficient airflow management for different applications.

HVLS Ceiling Fan Types

Product NamePowerAir Flow@0.00″SPRotation SpeedCFM/WattRemote Contral
24FT/7.3M Ceilling fan1500W / 2.0HP @ 3PH 460V530000 CFM55 RPM353RS485/0-10v BonaAPP
20FT/6.1M Ceilling fan1200W / 1.4HP@3PH 460V494000 CFM65 RPM412RS485/0-10v BonaAPP
18FT/5.5M Ceilling fan1000W / 1.3HP @ 3PH 460V441000 CFM72 RPM441RS485/0-10v BonaAPP
16FT/4.9M Ceilling fan1000W / 1.3HP @ 3PH 460V406000 CFM79 RPM406RS485/0-10v BonaAPP
